处理器
NVIDIA Jetson AGX Xavier
视频编码
4x 4K60 8x 4K30 16x 1080p60 32x 1080p30(H.265)
4x 4K60 8x 4K30 14x 1080p60 30x 1080p30(H.264)
视频解码
2x 8K30 6x 4K60 12x 4K30 26x 1080p60 52x1080p30(H.265)
4x 4K60 8x 4K30 16x 1080p60 32x 1080p30 2xNVDLA(H.264)
CPU
8-Core Carmel ARM V8.2 64-Bit CPU, 8MB L2 + 4MB L3
GPU
512-Core Volta GPU with 64 Tensor Cores
I/O
8xCSI GMSL 1xSPI 5xGPIO 2xUSB 3.1
1xGigabit Ethernet 2xCAN 5xUART 1xHDMI
1xMicro USB 2.0 Recovery 1xl2C 1xl2S
Sync I/O: 1xSYNC_IN, 2xSYNC_OUT, 2xSYNC_PPS
拓展接口
1xNano SIM Socket 1xTFSlot 1xM.2 For4G 1xM.2 For SSD
功能键
1xRecovery Button 1xPower Button 1xReset Button
尺寸
245mmx68mmx172mm (I/O ports and mountingholes included)2.2Kg
213mmx68mmx143mm (I/O ports and mountingholes excluded)
